XGecu T48 Newest Programmer Support 34000+IC for EEPROM/MCU/SPI/Nor/NAND Flash/EMMC/IC TESTER

XGecu T48 Programmer Instead of TL866CS TL866II runs under Windows XP,2003,2008,Vista  Win7 WIN8 WIN10 WIN11

XGecu T48 Programmer Product Description:

1. T48 (TL866-3G) programmer is the improvement of TL866II Plus programmer.
2. Support high-capacity NAND EMMC up to 256GB and programming speed is much higher.
3. Suppport high-voltage chips, VPP Maximum up to 25V.
4. Production of high-density SMD technology, a unified user interface, easy to use, fully functional, reliable program running of application software, ultra-small (size is almost the same as TL866II), code-runs much faster.
5. T48 offers significantly improved performance and excellent value for money.

EMMC Function Inrtoductions:

• Read and write speeds up to 17M Bytes/s, MAX capacity : 256GB
• Support ISP in-circuit programming

1b MODE speed: 4.7MB/s  4b MODE: 17MB/s

• Analysis EMMC fuctions

          Show emec manufacturing and device life time information
          Show memory usage of 8 partitions
          Each partitions shows whether it is write protected
          Shows whether the entire chip is temporarily or permanently  write protected
          Show whether the chip is password protected
          Show whether the emmc use a 32-bit security authentication  code to write to the RPMB.
          Show other important parameters Of ECSD/CSD/CID

• Read/write functionns (all functions can be completed with one-key)

1. Read CID CSD ECSD
2. CIear full-chip temporary write protection before programming
3. Clear temporary write protection groups before programming
4. Erase chip before programming
5. Blank check the chip before programming
6. Programming 32-bit authentication key
7. password verification
8. Partition Config
9. Read and Programming to B00T1
10. Read and Programming to BOOT2
11. Read and Programming to RPMB
12. Read and Programming tO GPP1/GPP2/GPP3/GPP4
13. Read and Programming user data(User Area)
14. Setting temporary write protection groups
15. Setting permanent write protection groups
16. Setting password (or reset password)
17. Programming ECSD
18. Programming CSD
19. Automatically verify the above operations after Programming

T48 (TL866-3G) English manual download link: (similar as TL866II/T56)

 https://cdn.shopify.com/s/files/1/0072/5424/5449/files/XGecu_T48_download_steps.pdf?v=1701166074

XGecu T48 Programmer Support Multi-language:

           English, Chinese, Russian, Polish, German, Spanish, Portuguese, Turkish, Czech,                 Italian

XGecu T48 Programmer Support System:

Windows XP、2003、2008、Vista Win7 WIN8 WIN10 WIN11

XGecu T48 Programmer Packing List:

1 * XGecu T48 universal programmer

1 * USB Cable
